FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature

Name: FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: FeCrAl255
Price: 26.00 USD
Availability: InStock

Productdetails

Plaats van herkomst: China

Merknaam: Tankii

Certificering: ISO9001

Modelnummer: FeCrAl255

Betaling & het Verschepen Termijnen

Min. bestelaantal: 10KG

Prijs: Onderhandelbaar

Verpakking Details: Spoel

Levertijd: 15-20 dagen

Betalingscondities: T/T

Levering vermogen: 500t/jaar

Krijg Beste Prijs

Contact opnemen

Specificaties

Beschrijving

Specificaties

Markeren:
                                                                              FeCrAl255 resistance wire 0.2mm, high temp FeCrAl wire for kiln, 25 gauge furnace resistance wire


Beschrijving

FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature

Good Quality 0Cr25Al5 Fecral Alloy Wire Heat Resistance for Oven

0Cr25Al5 is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by high resistance, low coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature.It is suitable for use at temperatures up to 1250°C.

Typical applications for 0Cr25Al5 are used in electric ceramic cooktop,industrial furnace,heaters.

Normal composition%

C	P	S	Mn	Si	Cr	Ni	Al	Fe	Other
Max
0.06	0.025	0.025	0.70	Max 0.60	23.0~26.0	Max 0.60	4.5~6.5	Bal.	-

Typical Mechanical properties(1.0mm)

Yield strength	Tensile Strength	Elongation
Mpa	Mpa	%
500	700	23

Typical Physical properties

Density (g/cm3)	7.10
Electrical resistivity at 20ºC(ohm mm2/m)	1.42
Conductivity coefficient at 20ºC (WmK)	13

Coefficient of thermal expansion

Temperature	Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC	15

Specific heat capacity

Temperature	20ºC
J/gK	0.46

Melting point (ºC)	1500
Max continuous operating temperature in air (ºC)	1250
Magnetic properties	magnetic

FeCrAl255 Resistance Wire 0.2mm Diameter for Kiln & Furnace Applications with 1250°C Operating Temperature 0
